Error Codes for Electronic Models of General Electric Dishwashers How Should Fault Codes Be Diagnosed?
Since the 1980s, GE dishwashers have been diagnostic. If your dishwasher detects a problem, an error code will appear on the screen. The error code is shown in the exact location as the numbers. A dishwasher error code indicates a particular problem. If your GE dishwasher isn’t working correctly, you may either look for GE dishwasher repair on YouTube or call GE to receive instructions on how to fix the device. How to clear the problem codes on your GE dishwasher is explained here.
What does FTD mean on the Dishwasher screen?
FTD on Dishwasher means faulty codes such as C1,C2,C3,C4,C5,C6,C7,C8,PF. Below are all the faulty codes and steps you need to do to fix the problem.
Error Code – GE Dishwasher PF
Condition = Power fail error
Repair or Check = dishwasher fails. Home power may be out. Restart and run the dishwasher.
Error C1 – GE Dishwasher
Error Condition = Draining Time Past 2 Minutes
Remove sink clogs. Unplug the dishwasher. Clean the dishwasher’s drain pipe. Replace a damaged draining hose. Check for a clogged drain pump. Remove any obstructions. Replace a broken drain pump.
Drain Hose or Pump
Error C2 – GE Dishwasher
Error condition = 7-minute draining time
Remove sink clogs. Unplug the dishwasher. Clean the dishwasher’s drain pipe. Replace a damaged draining hose. Check for a clogged drain pump. Remove any obstructions. Replace a broken drain pump. Press RESET to mute.
Drain Hose or Pump
GE Dishwasher – Error Code C3
Condition of error= Dishwasher Won’t Drain
Repair or Check = Remove sink blockages. Unplug the dishwasher. Clean the dishwasher’s drain pipe. Replace a damaged draining hose. Check for a clogged drain pump. Remove any obstructions. Replace a broken drain pump.
Drain Hose or Pump
Error code C4 – GE Dishwasher
Error condition = Dishwasher is overfilled
Cancel the wash cycle. After canceling, the dishwasher won’t empty—C3 problem code troubleshooting. Check the overfill float if the dishwasher drains after canceling the wash cycle. If there’s nothing beneath the overfill float, unplug the dishwasher and check the overfill float switch. Replace a broken overfill float switch.
Drain Pump, Drain Hose, Overfill Float Switch
Error code C5 – GE Dishwasher
Error condition = Dishwasher Doesn’t Have Enough Water (Drain Time Is Short)
Open the dishwasher’s water supply valve. Make that the dishwasher’s overfill float switch isn’t stuck in the up position. Turn off the dishwasher’s electricity and water. Check the water intake valve and fill line. If the intake screen is clogged, replace the water inlet valve; clearing the screen alone might cause flooding. Check the water intake valve harness for loose wires. If the water input valve doesn’t open, replace it.
Overfill Float Switch/Water Inlet Valve
Error code C6 – GE Dishwasher
Error condition = Too cold water (Water Not Hot Enough)
Turn on the sink’s hot water for 2 minutes. If the water is under 120F, adjust the water heater thermostat. You may break the sensor or control board if the dishwasher’s water supply exceeds 120F.
Temperature sensor or electronic control board
Error code C7 – GE Dishwasher
Repair or Check = Water Temp Sensor Faulty 5-minute power outage
Powering down the board resets it. If the error number C7 returns, plug in the dishwasher. If so, unplug the dishwasher and examine the water temperature sensor for loose connections. Replace the water temperature sensor if the wiring is secure. Replace the control board if the error returns.
Temperature sensor or electronic control board
Error code C8 – GE Dishwasher
The blocked detergent dispenser cover
Repair = Unblock the dispenser lid. Close the dispenser and restart the dishwasher. Check the cover 20-30 seconds into the cycle. If the detergent dispenser lid won’t open or it’s damaged, replace it.
Dispenser Assembly Replacement Parts
Opening of the cup
After adding the detergent, secure the cup since the detergent bottle has been left open. If there is a problem, the cycle will not start as it usually would. Tap the start pad once more if you do not want to proceed with opening the door.
A Leak Has Been Detected
There is evidence that there is a leak in the system.
The cycle will be terminated on models equipped with leak detection before it begins.
Frequently Asked Questions
- How can I tell whether the dishwasher I have from GE has an FTD code?
Failure to drink is indicated by the acronym FTD in GE dishwashers. Examine the dishwasher drain tube, pump, and filter for any signs of clogging.
- What does the number 2 error code mean for my GE dishwasher?
It may be possible to clear the error code by disconnecting the dishwasher for thirty seconds. In rare circumstances, service can be necessary. GE Appliances Factory Service is in charge of any necessary repairs.
- My 1-year-old GE dishwasher has fault code FTD (Failure to Drain). How do I repair it?
Dishwashers won’t drain for numerous reasons. The filter or hose may be clogged. Dishwasher drain tubes feature a removable check valve. Remove the cap from the drain bar if you have installed or updated the trash disposal. Make sure there’s no partial cap left. Unsecured drain hoses might also cause problems. The drain hose should be pretty high to avoid dishwashing backup. Dish soap residue may clog drains. If you observe suds in the dishwasher water, that’s evidence of ordinary dish soap residue from pre-soaking dishes or a low drain hose causing dishwater to back up into the drain hose. It might potentially be a drain pump obstruction or failure. When the dishwasher hasn’t emptied, start a cycle, then cancel it. Remove the filter only if the dishwasher is dry. Removing the filter may enable particles in the dishwasher’s undrained water to harm or impede the pump. When you start a cycle, cancel it and wait 2 minutes, the water should drain, and you may clean the filter without dirt. Otherwise, the drain pump impeller may be fractured, or you may break it.
